Qcells Q.Volt H7.6SX Hybrid Inverter with 3 MPPT - SSDW-00007 | High-Performance Solar Inverter

The Qcells Q.VOLT H7.6SX (Model: SSDW-00007) is a high-performance hybrid inverter designed for residential solar energy systems. It efficiently manages energy from solar panels, batteries, and the utility grid, ensuring optimal energy utilization and providing backup power during outages.

Key Features:

• Hybrid Functionality: Seamlessly integrates solar power, battery storage, and grid electricity to optimize energy usage.
• Multiple MPPTs: Equipped with three Maximum Power Point Trackers (MPPTs) to maximize energy harvest from solar panels.
• High Efficiency: Achieves a maximum efficiency of 97.5%, ensuring minimal energy loss during conversion.
• Backup Power Capability: Provides reliable backup power during grid outages, maintaining the operation of essential household appliances.
• Remote Monitoring: Offers real-time monitoring and management via the Q.HOME web portal or mobile app, providing insights into energy consumption and system performance.

Specifications:

• Model Number: SSDW-00007
• Nominal AC Power: 7.6 kW
• Maximum DC Input Voltage: 550 V
• MPPT Voltage Range: 90 to 500 V
• Number of MPPTs: 3
• Nominal AC Voltage/Frequency: 240 V / 60 Hz
• Maximum AC Current: 31.7 A
• Battery Type: Lithium-ion (LFP)
• Maximum Charge/Discharge Current: 54 A
• Efficiency: 97.5% (CEC weighted)
• Operating Temperature Range: −13°F to +140°F (−25°C to +60°C)
• Protection Rating: NEMA 4X, suitable for indoor and outdoor installations
• Dimensions (H x W x D): 33.1 x 15.7 x 5.7 inches (840 x 400 x 145 mm)
• Weight: 75 lbs (34 kg)
• Warranty: 10 years

The Q.VOLT H7.6SX inverter is an integral component of the Q.HOME CORE energy storage solution, offering homeowners a reliable and efficient means to manage their energy needs. Its advanced features and robust design make it a suitable choice for modern residential solar installations.
